Z510Y self operated pressure regulating valve is mainly applicable to the occasions where the pressure regulating ratio before and after the valve is small, and the pressure set point is 8~3500kpa. Widely used in various industrial equipment for automatic control of gas, liquid, and steam media pressure reduction and stabilization or pressure relief and stabilization.
Standard specifications
Type | Self-Operated Pressure Regulating Valve |
Body Size | DN15-DN450 (1/2-18) |
Body Ratings | PN10、16、20、25、40、50、64、100、110、150、250、320、420 |
Body & Bonnet Material | WCB, CF8, CF8M，CF3, CF3M, WC1, WC6, WC9, LCB, LCC, LC3... |
Packing | V-PTFE/ Flexible Graphite |
Gasket | GRAP+304, GRAP+316, PTFE |
Opening pressure error | When the set pressure is 0.5MPa or above, the allowable deviation is 3% of the set pressure. When the set pressure is less than 0.5MPa, the allowable deviation is ±0.014MPa. |
Connections | Welding type (SW,BW)/ Flanged(RF、MFM) |
Painting color | Brown paint/ No painting on stainless steel valve body/silver paint... |
Pressure regulating scope (KPa) | 8-18 15-50 40-80 60-100 80-140 120-180 160-220 200-260 240-300 280-350 330-400 380-450 430-500 480-560 540-620 600-700 780-900 880-1000 950-1100 1080-1250 1230-1400 1380-1550 1530-1800 1780-2000 1980-2300 2280-2500 2300-3000 2800-3500...（high pressure and special regulating scope shall be decided according to practical situations) |
Note: The above are only standard combinations, and specifications outside of this table are also possible depending on the operating conditions.
